WirelessUSA Inc.

Interoperability Applications

CVT-TRBO-PP

LTR/Passport GOB Application

SCHOLER-JOHNSON INC

Firmware application for the Generic Option Board to allow the MOTOTRBO radio to support LTR, Classic PassPort and Enhanced PassPort in Analog mode.

Provides a clear migration path from Analog operation to Digital operation for users with existing LTR or PassPort systems/networks.

Key Benefits

  • QA01839, available as a factory-installed option in North America.
  • Allows users to add digital-capable radios to their existing analog fleet to facilitate migration to digital operation.
  • Allows users to operate one radio on MOTOTRBO digital platforms (except for Connect Plus) and Analog LTR and/ or PassPort.

Key Features

  • Up to 256 Zones, up to 256 Groups/Channels per Zone.
    *Supports over 2000 total Groups/Channels.
  • Programming via standard MOTOTRBO USB programming cable.
  • Field upgradeable via standard MOTOTRBO USB programming cable.
  • (LTR/Conventional) Pre-Only MDC PTT ID.
  • (LTR/Conventional) User selectable scanning across Zones.
  • (LTR/PassPort) User selectable Group Scan.
  • (PassPort) Enhanced and Classic operation.
  • (Enhanced PassPort) Integrated network Emergency call operation.
  • (Enhanced PassPort) Subscriber priority access.
  • (Enhanced PassPort) Automatic Channel backup.
  • (Enhanced PassPort) Expanded neighbor list.
  • (Enhanced PassPort) Message Trunking.
  • (Enhanced PassPort) Roam registration on free channel.

CVT-TRBO-PP Application

System Requirements And Types

  • Radio Hardware/Releases Compatibility:
    • Analog Capable MOTOTRBO radio with a Generic Option Board installed.
  • Interfaces:
    • A PC running Windows XP or later is required for programming the

Industries

Fire & Emergency Medical Services, Healthcare. Hospitality, Mining, Oil & Gas, National Government Security, Police, Public Services (non-public Safety Government), Retail, Transportation & Logistics, Utilities.

Application Partner

Motorola Application Partner
